5000L water treatment system device parameters
5 tons of stainless steel industrial water treatment equipment, industrial water purification equipment, customized.
Reverse osmosis pure water equipment
Capacity: 5000L/h
Power supply: 380v/50hz/4.1kw Three-phase electricity
Size:3500*700*200mm
Weight: ~380kgs
Note:
1. EXW.
2. Price validity period: 10 days
3. Payment method: telegraphic transfer to bank, 100% advance payment.
4. Delivery date: 30 days after the first payment.
Warranty
The warranty period for the machine after delivery is 12 months. The machine provides free electronic components (excluding consumables). Once the machine malfunctions, you can send us photos or videos of the malfunction, and we will provide a solution to the problem within 24 hours.
|
order number |
Device Name |
specifications |
number |
material quality |
|
一 |
raw water system |
|||
|
1 |
Pretreatment Booster pump |
Model: 8-30 Flow rate: 8m3/h Lift: 30m Power:1.8W/unit |
1 unit |
SHIMGE |
|
二 |
pretreatment system |
|||
|
1 |
quartz sand filter |
|||
|
canister |
Ø600*1900 |
1 unit |
TRP |
|
|
Center pipe, upper and lower water distributors |
Supporting facilities |
1 set |
UPVC |
|
|
Top mounted automatic recoil head |
5T/H, LCD display, digital programming |
1 unit |
Runxin |
|
|
filter material |
2-4，4-8 |
1 set |
Refined granite filter material |
|
|
pressure gage |
1.0MPA |
1 pcs |
Stainless steel |
|
|
Pipe valve components |
Ø40 |
1 set |
UPVC |
|
|
2 |
Activated carbon filter |
|||
|
canister |
Ø600*1900 |
1 unit |
TRP |
|
|
Center pipe, upper and lower water distributors |
Supporting facilities |
1 set |
UPVC |
|
|
Top mounted automatic recoil head |
5T/H, LCD display, digital programming |
1 unit |
Runxin |
|
|
filter material |
Special for water treatment |
1 set |
Fruit shell activated carbon filter material |
|
|
pressure gage |
1.0MPA |
1 pcs |
Stainless steel |
|
|
Pipe valve components |
Ø40 |
1 set |
UPVC |
|
|
3 |
Resin softening filter |
|||
|
canister |
Ø600*1900 |
1 unit |
TRP |
|
|
Center pipe, upper and lower water distributors |
Supporting facilities |
1 set |
UPVC |
|
|
Automatic regeneration control machine head |
5T/H, LCD display, digital programming |
1 unit |
Runxin |
|
|
filter material |
cation exchange |
1 set |
resin |
|
|
Salt box |
100L |
1 unit |
PE |
|
|
pressure gage |
1.0MPA |
1 pcs |
stainless steel |
|
|
Pipe valve components |
Ø40 |
1 set |
UPVC |
|
|
4 |
Security filter |
5-core 40 inch |
1 unit |
stainless steel |
|
Precision filter element |
5 microns |
5pieces |
PPM |
|
|
pressure gage |
1.0MPA |
1 pcs |
stainless steel |
|
|
Pipe valve components |
Ø40 |
1 set |
UPVC |
|
|
三 |
RO system |
|||
|
1 |
Booster pump |
Model: 4-160 Flow rate: 5m5/h Lift: 165m Power: 5KW/set |
1 unit |
SHIMGE |
|
2 |
RO reverse osmosis membrane |
8040 |
5 pieces |
Dow |
|
3 |
High pressure membrane housing |
8040 20MPa |
5 pieces |
glass fiber reinforced plastics |
|
4 |
Pipe valve components |
Ø40 |
1 set |
UPVC |
|
四 |
Instrumentation and control system |
|||
|
1 |
instrumented system |
|||
|
Produced water conductivity meter |
MP-230 |
1 unit |
combination |
|
|
Low voltage protection switch |
60A |
1 pcs |
combination |
|
|
High voltage protection switch |
60A |
1 pcs |
combination |
|
|
Water inlet solenoid valve |
Ø40 |
1 pcs |
combination |
|
|
Flushing solenoid valve |
Ø32 |
1 pcs |
combination |
|
|
Concentrated water regulating valve |
Ø32 |
1 pcs |
combination |
|
|
Purified water flow meter |
0-10T |
1 pcs |
combination |
|
|
Concentrated water flow meter |
0-10T |
1 pcs |
combination |
|
|
pressure gage |
0-1.0MPa |
4 pcs |
stainless steel |
|
|
2 |
Automatic control electric control cabinet |
Chint Electric Appliances |
1 unit |
Stainless steel cabinet body |
|
五 |
Racks, pipe valves, wires and cables |
|||
|
1 |
rack |
Supporting facilities |
1 unit |
stainless steel |
|
2 |
Equipment pipes and valves |
Supporting facilities |
1 set |
UPVC |
|
六 |
UV |
|||
|
2 |
UV |
135W |
1 set |
stainless steel |
